dmc eurosystem
(512) 931-1962
Excellent finishing results are obtained when machining raw and painted panels thanks to the wide range of units (Cross-Belt, Calibrating Roller, Sanding Roller, Super-Finisher) that come with the dmc eurosystem, and to its prescribed approach: a perfect combination of aggressive roller with sensitive EPICS electronic sectional pad.
DIGITAL READ-OUT: the device detects the working height of the roller and makes the reading of the value immediate and precise.
HIGH PERFORMANCE TRANSMISSION SYSTEM: the “POLI-V” belt ensures an extremely powerful, efficient and silent transmission; in addition, the automatic belt tensioning system guarantees that the tension remains constant over time.
HIGH-EFFICIENCY DUST SUCTION HOODS: expressly studied and designed by DMC engineers, allowing to control the dispersion of the dust even in the heaviest working conditions, thanks to their particular shape and position, very close to the working area.
MAESTRO ACTIVE SAND: SIMPLE AND RELIABLE
The brand new “Maestro active sand” HMI allows you to set all the machining parameters from the 24'' “eye-M” or 15'' "eye-S" console and to check the correct operation of the machine in real time. Featured with all-new functionalities wich include:
- Tool store management: it enables to execute the inventory of all the tools available on the store, to indicate the quantity per type of belts and to warn automatically when they are running out;
- Pre-arrengement for Maestro connect;
- Industry 4.0 ready.
| Working width | mm | 1350 |
| Min/max working thickness (mobile table) | mm | 3-170 |
| Min/max working thickness (constant pass-line) | mm | 3-200 |
| Abrasive belt width (roller unit) | mm | 1370x2620 |
| Abrasive belt length (roller unit) | mm | 150x5000 |
| Mat feed speed | m/min | 3-18 |
