Edge banders, squaring edge banders - Single-sided automatic edge banders - stefani s

stefani s is the single-sided edgebanding machine designed for medium-and large-scale firms and leader in the market, is characterized by its precise machining operations, reliability and efficiency. Suitable for machining edges in plastic material, both traditional and modern, wood and laminate strips, even aluminium edges. It offers a complete range of machining operations for diversified industrial production at reduced costs.

Advantages

MODULARITY
stefani s can be “tailor-made” for the individual customer, according to his own qualitative and performance requirements, for both the traditional machining of straight panels and soft-forming machining.

INTEGRATION
stefani s can be used in edgebanding cells, with automations for the panel return to the operator, with devices for manual or semi-automatic panel insertion, and with devices for automatic panel loading. It can also be inserted in a line with other machines.

TECHNOLOGY
stefani s guarantees the highest quality thanks to the best technology available in every area of the machine. AirFusion+, SLIM LINE, SGP glue pot, ZERO LOCK, NESTING LOCK, are just some of the exclusive technologies to guarantee a finished product at the top.
Technical data
Max working speed
m/min
25 (30 opt)
Coil edge thickness
mm
0.3-3
Pre-cut strip thickness
mm
0.4-1
Solid wood thickness
mm
25
Panel thickness
mm
10 – 60 (80 opt)
PANEL DIMENSIONS WITH COIL EDGE


Min/max panel length
mm
135 (125 opt)-3200
Min/max panel width
mm
95 (55 opt)-1200
Pneumatic system
MPa
6
Technology for edge application

EVA, PUR, EVA+PUR
AirFusion
SLIM LINE

TYPE OF EDGE
EXAMPLE OF APPLICATION
MAX THICKNESS
Paper
Raw / prepainted
0,6 mm
Plastic in coil
ABS, PVC, PP (with/without film)
PMMA (polished or rough to polish/smooth)
3 mm
Alluminium
Shine/ Satin
3 mm
Pre-cut strips
Veneer, PC, Unicolor
1 mm
Solid wood
Raw / polished / drawn
25 mm
