minimax st 4e

(512) 931-1962
Máquinas para carpintería - Sierras - tupís - minimax st 4e

Sierra-tupí para los artesanos y las carpinterías exigentes con las prestaciones de máquinas mono-función para responder a las necesidades de flexibilidad y acabado "de élite".

Ventajas

Stabilidy and rigidity
The new saw unit closed loop structure is made of a heavy cast iron and is supported firmly under the table by two lateral supports in a crescent shape. These solutions give strength and rigidity, guaranteeing perfect cutting results. The saw unit can be equipped, on request, with scoring blade for perfect cutting even on veneered panels. The scoring blade is an optional available in two versions: with belt transmission from the main motor and with an independent motor 0.75 HP (0.55 kW). The maximum diameter allowed for the main saw is 315 mm with scoring blade mounted.

Precise and silent
Optimal support also to larger pieces, with the sliding table 360 mm wide. Exceptional precision and smoothness: to secure the guides it is not used glue, since the thickness could affect sliding. They are secured with a procedure of aluminum riveting.

Versatility
Maximum stability and rigidity in all working conditions, thanks to a large spindle moulder column made entirely of cast iron. The 4 standard speed are ideal for any type of machining, from moulding to routing and tenoning, with the possibility to fit tools upto 275 mm of diameter.The spindle is surrounded by a cast iron “cup” to protect the internal mechanical components from shavings and sawdust.

High-tech accessories
As option it is available the spindle moulder hood that uses a system for adjusting the guides with a rack and it is fitted with a mechanical digital readout. Thanks to the system of memories the hood can be removed and repositioned without losing the machining position. The maximum tool diameter during moulding operatrions is 240 mm.

Ficha Técnica
st 4e
Diámetro máx. disco sierra con incisor instalado mm 315
Saliente máx. disco sierra de la mesa a 90°/45° mm 100/70
Ancho de corte en la guía paralela mm 900 ÷ 1270
Capacidad de escuadrado mm 1660 ÷ 3200
Longitud útil del eje tupí mm 125
Velocidad de rotación eje tupí (a 50 Hz) giros/min 3500/6000/8000/10.000
Diámetro máx. de la herramienta a perfilar mm 210 ÷ 240
Diámetro máx. de la herramienta entrante bajo la mesa a 90° mm 240
Diámetro máx. de la herramienta a espigar mm 275
Potencia motores trifásico a partir de kW/Hz 4 (4,8) / 50 (60)
