Joinery machines - Sanders - minimax ls

Belt sander with double gooseneck for craftsmen and professional workshops.


Excellent stability and high precision without vibrations, with the heavy duty structure. Maximum machining comfort with the perfect carriage sliding and with all the controls easy-to-use and located within easy reach of the operator. Clean and healthy working environment, thanks to the two dust exhaust hoods.

Technical data
LS 2500
Worktable length (standard) mm / ft 2500 / 8.2
Worktable width mm / ft 1100 / 3.6
Worktable vertical stroke mm / inches 580 / 23
Belt speed (two speed) fps 29 / 59
Gooseneck depth mm / inches 820 / 32
Three-phase main motor Hp 4.8
Three-phase table lifting motor Hp 0.6
Table Dimensions inches 98.4 x 43
Belt length inches 279
