mahros runner
Portal-framework feeder and stacker

Feeder and stacker with double or single loading or unloading station. Designed to integrate within production lines for drilling, squaring, edgebanding, squaring-edgebanding, routing, sanding and painting with no need of manual operator intervention.
Fully automatic, it does not require manual adjustments during the working process.

Advantages
  1. Fast
  2. Reliable
  3. Optimal price-performance ratio



Technical data
Panel length mm 230 - 3200
Panel width mm 210 - 1300 (single row)
210 - 600 (double row)
Panel thickness mm 10 - 60
Panel maximum weight Kg 100
Cycle/minute   13
