oikos x is the CNC machining centre for the production of structural beams and X-lam/CLT wall panels up to 1250 mm wide. The innovative 6-axis operating unit allows any machining operation on all faces of the element in a single positioning and with no rotation required.
Synchronised movements and new strategies make it possible to achieve high machining speeds and perfect quality of the finished product.
TECHNOLOGY WITHOUT LIMITS
The new 6-axis symmetrical operating unit has been designed to perform all the machining operations necessary for the production of structural beams, wall panels and insulating panels with maximum speed and top quality. Its perfect symmetry allows processing both ends of each element in minimum overhang conditions.
UNRIVALLED MECHANICS
The sturdy structure of the machining centre ensures the optimal absorption of the stresses deriving from the element processing, guaranteeing a high constant precision over time. The machine base fixed directly to the ground, without the need of building work, increases the machine stability and performance.
EFFICIENT CLEANING
Cutting-edge technical solutions also for the containment of dust and for the management of machining waste. The presence of casings with automatic closing, combined with the efficiency of the removal system, allows physically separating the work area from the external environment, eliminating machine downtime due to the rehabilitation of the work environment.
PROGRAMMING FREEDOM
Maestro beam&wall is the proprietary SCM software compatible with the most popular CADs design systems in the timber building industry. It allows programming both in the office and directly on the machine. Thanks to the new HMI software Maestro active beam&wall, control and optimization of the production flow are even simpler and more intuitive.
| Workpiece dimensions | ||
| Length max. | mm | 9,000 - 13,500 - 19,000 |
| Cross-section max. | mm | 1,250 x 300 |
| Cross-section min. | mm | 50 x 20 |
| Weight max. (for the automatic loading) | kg | 2500 |
| Weight max. (for the manual loading) | kg | 4000 |
| Main operating unit | ||
| Axes | N° | 6 |
| Power max. (S1) | kW | 13 - 25 |
| Sawblade diameter | mm | up to 600 |
| compatible with tool store | yes | |
| Tool store | ||
| Positions | N° | 18 |
