accord 25 fx

Name: accord 25 fx
Brand: SCM

(512) 931-1962

CNC machining centre providing utmost performance with minimum investment.
Designed to meet the needs of small and medium-sized companies, it combines state of the art technology with extreme ease of use for flexible productions of doors, windows, stairs, solid wood parts and for machining wooden and extra-wooden panels: plastic, composites, resins and light alloys.

Advantages

HEAVY DUTY PROFILING
The PRISMA machining heads with 5 interpolating axes are designed for the processing of solid wood.
The ideal solution for windows, doors and stairs.

RAPID AND PRECISE SET-UP
The MATIC bars worktable with direct transmission system and independent drive units, assures the complete set-up in seconds.
Simple and quick replacement of clamps and suction cups through the exclusive rapid locking device.

PERFECT FINISH QUALITY
The architecture with fixed table and mobile gantry structure, consisting of a sturdy construction equipped with front and rear sliding guides, ensures maximum accuracy and finish quality over the entire work area.

INTELLIGENT PROGRAMMING
Simple and intuitive programming, thanks to the MAESTRO software that includes modules for different applications.

Technical data

		accord 25 fx
Working areas
X-Y-Z axes dimensions	mm	3680x1380x250 5020x1380x250 6360x1380x250 3680x1680x250 5020x1680x250 6360x1680x250
Axes
X-Y-Z axes max. speed	m/min	60-60-30
Machining head
5 axes electrospindle motor power (max.)	kW	12
3/4 axes electrospindle motor power (max.)	kW	15
5 axes electrospindle rotation speed (max.)	rpm	24000
3/4 axes electrospindle rotation speed (max.)	rpm	24000
Tool stores
Tool store on machining head	positions	12
Rear tool store	positions	32
Side tool store	positions	12
Drilling unit
Vertical and horizontal spindles (max.)	n.	30
Rotation speed (max.)	rpm	8000
