Máquinas para carpintería - Sierras - tupís - minimax st 5es
Sierra-tupí cuyas soluciones técnicas profesionales la hacen inigualable en prestaciones y fiabilidad.
Ventajas

Unique in the world in its category! The cast iron saw unit with a rigid closed loop structure can accommodate a blade of max. 400 mm diameter (for si 400es and Nova si 40) with the scoring blade mounted, ensuring perfect and easy cutting of veneer panels and thick solid wood material. The saw blade uses 100% of the motor power, thanks to the scoring blade with an independent motor as standard. The rotation fulcrums of the saw unit have a 120 mm diameter and stand on steady crescent shaped rests that separate it from the base: a rigid reliable solution.

Unrivalled cutting finishing
Optimal support also to larger pieces, with the sliding table 360 mm wide. Exceptional precision and smoothness: to secure the guides it is not used glue, since the thickness could affect sliding. They are secured with a procedure of aluminum riveting.

Unsurpassed moulding
Maximum stability and rigidity in all working conditions, thanks to a large spindle moulder column made entirely of cast iron. The 4 standard speed are ideal for any type of machining, from moulding to routing and tenoning, with the possibility to fit tools upto 320 mm of diameter (300 mm no CE).

Immediate control
Panel loading is easy on the large squaring frame with an idle roller at the end. The telescopic squaring fence with the inclined metric scale and two reversible stops can be used to square panels measuring 3200 x 3200 mm and for miter cuts at up to 45° on both sides of the frame.

Ficha Técnica
st 5es
Diámetro máx. disco sierra con incisor instalado mm 350
Saliente máx. disco sierra de la mesa a 90°/45 mm 118/84
Ancho de corte a la guía paralela mm 900 ÷ 1270
Capacidad de escuadrado mm 2250 ÷ 3200
Longitud útil eje tupí mm 125
Velocidad de rotación eje tupí (a 50 Hz) giros/min 3500/6000/8000/10.000
Diámetro máx. de la herramienta para perfilar mm 240
Diámetro máx. de la herramienta entrante bajo la mesa a 90° mm 240
máx. de la herramienta para espigar mm 320 (300 no CE)
Potencia motores trifásicos a partir de kW/Hz 5 (6) / 50 (60)
